Flexible Invisibility Material. Upgraded Invisibility Shields. Passive Cloaking.
Check on Kickstarter
We've created flexible, rollable invisibility material for custom cloaking applications as well as complete, freestanding invisibility shields in both flat and curved versions.
Invisibility Material (Half Size)
Products
Invisibility Material
These are rollable, flexible sheets of cloaking material that you can use for your custom projects such as hiding large objects by tiling sheets of material together or creating privacy screens of all shapes.
These sheets do not stand up on their own so they need attaching to a structure, window or frame to remain in place.
The Invisibility Material (Full Size) tier can be supplied with an adhesive backing, this option can be selected during the post campaign survey.
Three sizes are available (Mini, Half Size & Full Size)
Curved Invisibility Shields
Two sizes available (Full Size and Megashield)
Complete invisibility shield
Stands up on its own
Packs down fully into a small carry case (the front of the shield rolls up)
Ergonomic handles allow you to stay more hidden when moving
Hides you better from a wider viewing angle (from the sides)
Flat Invisibility Shield
One size available (slightly smaller than the curved full size)
Complete invisibility shield
Stands up on its own
Does not pack down small (the shield face is thick and cannot be bent)
Hides you a little better when viewed straight on
Size Guide
Passive Cloaking
No batteries are required (for our shields or invisibility material). Simply assemble your shield and place it in front of whoever or whatever you wish to cloak.
Left – Full Size Shield (Curved), Right – Megashield (Curved)
Full Size Shield (Flat)
You May Have Seen Us In The News!
How It Works
Each shield uses a precision engineered lens array to direct light reflected from the subject standing behind it, away from the observer standing in front. The lenses in this array are oriented so that the vertical strip of light reflected by the standing/crouching subject becomes diffuse when spread out horizontally on passing through the back of the shield. In contrast, the strip of light reflected from the background is much wider, so when it passes through the back of the shield, far more of it is refracted both across the shield and towards the observer. From the observer's perspective, this background light is effectively smeared horizontally across the front face of the shield, over the area where the subject would ordinarily be seen.
The optical arrays we use to construct our shields are manufactured by extruding and then embossing a polymer to form sheets of elongate, convex lenses. In order for these sheets to manipulate light in the right way to create functional invisibility shields, the lenses must have a highly specific shape and each one must be formed with high precision as they are very small. To find the best properties for a shield, we've spent years testing different lens shapes with varying profiles, angles, depths, focus points and separation distances.
Full Size Shield (Curved)
The shields perform at their absolute best against uniform backgrounds such as foliage, grass, rendered walls, sand, sky and asphalt. Backgrounds with defined horizontal lines work extremely well too and these can be natural features such as the horizon or man made features like walls, rails or painted lines.
Full Size Shield (Flat)
The World's Biggest Invisibility Shields
Whilst our Full Size Shields have ample room to hide a single person, our Megashields measure over 6ft (1.8m) tall, making them large enough to hide multiple people standing side by side.
Megashield (Curved)
Design Upgrades
Higher clarity (invisibility material)
Thicker fittings for increased durability (complete shields)
Scratch resistant coating for increased durability (all products)
An entire secondary shield face supplied as standard (curved shields only)
Adjustable hand holds (curved shields only)
Tougher carry case & straps (curved shields only)
Printed instructions (all products)
Spares for small parts included as standard (complete shields)
Megashield (Curved)
Curved Shields That Pack Down Small
Our curved shields won't take up valuable space when you're not using them. The Full Size Shield (Curved) and the Megashield (Curved) can be completely disassembled and packed down in dedicated carry cases (available to add on after the campaign during the survey process).
Rapid Assembly
Our complete shields take the average novice 10 minutes to set up and pack for the first time and the Megashield takes around 15 minutes (with two people). We recommend setting up and handling the Megashield with two people on account of its size.
